The required fire resistance class for a door opening is determined by a combination of the applicable building regulation, the project-specific fire safety calculation, and the functional demands of the opening itself. There is no single universal answer: the Dutch BBL (Besluit Bouwwerken Leefomgeving, formerly Bouwbesluit) sets a minimum baseline, but project deviations, sector regulations, client requirements, and insurer demands can all push the specification higher. The sections below work through each of the key questions an architect or specifier needs to answer before writing a fire door into a design.
What factors determine the required fire resistance class for a door opening?
The required fire resistance class for a door opening depends on the fire compartmentation strategy defined in the project’s fire safety report, the building type and use, the size of the fire compartment, and any sector-specific regulations or insurer requirements that apply. The BBL provides the statutory floor, but the actual specification is always project-specific.
In practice, a fire safety engineer or consultant produces a fire safety calculation that determines which openings need protection, at what performance level, and for how long. That calculation takes into account the occupancy type, the escape route layout, the maximum permitted compartment size, and whether the building falls under additional regulatory frameworks such as PGS15 for hazardous substances storage.
Architects working on industrial buildings — logistics centres, production halls, healthcare complexes — frequently encounter openings that go well beyond standard residential requirements. Large passage widths for internal transport, high ceilings, and complex occupancy mixes all influence which classification applies. Specifying a door without first confirming that the fire safety calculation is complete is one of the most common sources of design revision late in a project.
For architects who want to cross-check their specification against a manufacturer’s certified range, Metacon-Next’s product range covers fire resistance classes from EW 60 through to EI(1) 120 and EI(2) 120 across multiple door types, including openings that standard products cannot accommodate.
What is the difference between EI1, EI2, and EW classifications?
EI1, EI2, and EW are three distinct fire resistance classifications for door assemblies under EN 13501-2, each measuring a different level of thermal performance. All three share the E criterion — integrity, meaning flames and hot gases are stopped. The W criterion additionally limits radiant heat transfer through the door assembly; this is the Dutch standard baseline criterion. The I criteria go further by also controlling the surface temperature on the unexposed side: EI2 limits the average temperature rise on the unexposed face, while EI1 applies a stricter limit that also constrains localised temperature rise at any single point.
The practical consequence is significant. An EW-classified door limits radiant heat transfer but does not control the surface temperature on the unexposed side. An EI2 door provides a higher level of thermal insulation, making it suitable for escape routes and areas where people may be present near the door during a fire. An EI1 door meets the strictest insulation criterion and is specified where the most demanding thermal separation is required.
These classifications are defined under EN 13501-2, the European standard for fire resistance classification of construction products and building elements. When writing a specification, always use the EN 13501-2 classification code that corresponds to the performance level required by the fire safety calculation.
Never write EI without specifying whether it is EI1 or EI2. They represent meaningfully different levels of insulation performance, and substituting one for the other in a specification is not a minor administrative error — it changes the product category entirely.
What does the Dutch BBL specify about fire door classifications?
The Dutch BBL (Besluit Bouwwerken Leefomgeving, formerly Bouwbesluit) sets the minimum fire resistance performance required for separating elements, including door openings, in different building types and occupancy categories. It does not prescribe a single fixed classification for every situation — it establishes a statutory floor below which no compliant design may fall.
The BBL operates on the principle that fire compartmentation must limit fire spread between defined areas of a building. For door openings in compartment walls, the required performance is expressed in terms of fire resistance duration (typically 30, 60, or 90 minutes) and the applicable classification criterion. The Dutch standard baseline for the W criterion is EW 60, though other classifications such as EI2-60 are common and fully valid alternatives, not exceptions. The BBL’s minimum requirements are frequently exceeded in practice: project-specific fire safety calculations, sector regulations such as PGS15, client requirements, and insurer conditions routinely result in specifications that go beyond the statutory minimum.
Architects should treat the BBL as the starting point of the specification process, not the endpoint. A door that meets only the BBL minimum may not satisfy the fire safety report, the environmental permit, or the building insurer. Confirming alignment between all applicable requirements before specifying a product is part of the architect’s design responsibility. When in doubt about which classification applies to a specific situation, consult a qualified fire safety engineer or contact Metacon-Next directly — the correct answer depends on a project-specific calculation, not a general rule.
When is EI2 required instead of EI1 or EW?
EI2 is required when the fire safety calculation or applicable regulation specifies that the unexposed face of the door assembly must remain below defined temperature limits — typically because the door borders an escape route, a space where people may be present during evacuation, or a zone where limiting radiant heat transfer alone is not a sufficient control measure. EW is insufficient in these situations because it does not control surface temperature on the unexposed side. EI1 applies only when the strictest localised temperature criterion is required.
In industrial buildings, EI2 is commonly specified for doors that separate production or storage areas from corridors, stairwells, or other protected routes. The reasoning is straightforward: if a person is evacuating past a fire door, the surface temperature of that door on their side must not itself become a hazard. EW does not guarantee this. EI2 does, within the limits of the classification duration.
EI1 is less frequently specified in standard industrial applications but becomes relevant where the most stringent thermal separation is required, such as in certain healthcare or high-risk occupancy contexts. Whether EI1 or EI2 applies to a specific opening is determined by the fire safety report, not by the architect’s judgment alone. If the report does not specify the insulation criterion explicitly, clarification from the fire safety engineer is required before the specification is finalised.
What documentation proves a fire door meets the specified classification?
A fire door meets its specified classification when it is accompanied by a CE declaration of performance, a classification report issued by an accredited testing body, and test evidence produced in accordance with EN 1634-1. These documents together demonstrate that the product was independently tested, that the test conditions match the intended application, and that the classification is valid for the door configuration as supplied.
For architects, the documentation requirement is not merely procedural. It is the basis on which a permit-ready design can be defended during a building control review or fire safety inspection. If a supplier cannot provide complete documentation at the specification stage — not after order placement — the specification carries risk that sits with the design team.
The key documents to request are:
- CE declaration of performance — confirms the product meets the requirements of the Construction Products Regulation (CPR). Note that for industrial fire doors, CE marking is governed simultaneously by EN 16034 (fire- and smoke-resisting closing elements) and EN 13241 (industrial doors generally); both apply and must not be treated as interchangeable.
- Classification report — issued by the testing body (such as Efectis) and identifies the exact product configuration that achieved the stated classification under EN 13501-2
- Test report — the underlying evidence from the fire resistance test conducted under EN 1634-1; where smoke control performance is also certified, a separate test under EN 1634-3 applies
- Environmental Product Declaration (EPD) — increasingly required for BREEAM and LEED-rated projects, and available for most Metacon-Next product lines
Metacon-Next publishes its certificates, classification reports, and EPDs openly. This is not a regulatory requirement — it is a deliberate choice that allows architects to verify documentation without requesting it through a sales process. If you are evaluating any fire door supplier, it is worth asking whether their full documentation is publicly available before the specification is written. Metacon-Next’s approach to certification is built around that transparency.
How do custom dimensions affect fire resistance classification?
Custom dimensions affect fire resistance classification because a door’s tested performance is valid only within the dimensional limits established during the fire resistance test. If a door opening exceeds those limits in width, height, or both, the classification cannot automatically be extended to the larger configuration — additional testing or an extended application of test results (as governed by EN 15269-1 to -20) is required to confirm that the classification remains valid.
This is a frequent issue in industrial construction. Warehouse openings for forklift passage, wide roller door openings in production halls, and oversized sliding doors in logistics facilities all routinely exceed the dimensions covered by standard test evidence. An architect who specifies a fire resistance class without confirming that the manufacturer’s test evidence covers the required opening size has introduced a compliance gap into the design.
Metacon-Next’s in-house R&D department develops products specifically for large and atypical industrial openings. The company’s fire-rated industrial door range includes configurations for openings that standard products cannot accommodate, with classification reports that cover the relevant dimensional envelope. When specifying for non-standard dimensions, confirming the scope of the manufacturer’s test evidence is a necessary step before the specification is finalised.
For projects where dimensional requirements are still being defined, contacting Metacon-Next directly allows architects to confirm whether a specific configuration falls within tested limits or requires additional technical assessment. The company’s MetaConfigurator portal also provides 24/7 access to dimensional data, technical drawings, and BIM files — so the information needed to close a specification does not depend on a sales conversation.
Determining the right fire resistance class is a multi-step process that begins with the fire safety calculation and ends with verified documentation for the exact door configuration specified. Each step — classification type, duration, dimensional scope, and supporting evidence — carries design and regulatory weight. Which classification is ultimately required depends on a project-specific calculation; a qualified fire safety engineer or the local authority is best placed to confirm this for your project. Request a quotation from Metacon-Next to receive product-specific technical documentation aligned to your project requirements, or explore the full Metacon-Next range to identify which door types and classifications apply to your application.
