Fire rated roller shutters

Fire does not spread randomly. It follows air, space and structure. Fire rated roller shutters are designed to interrupt that movement. They close openings and slow down the spread of flames and smoke.

A roller shutter fire rated system gives you control in a critical moment. It separates areas inside a building and keeps damage contained for a defined time. That time helps people leave safely and gives emergency services space to act.

What are fire rated roller shutters?

Fire rated roller shutters are steel shutters that close automatically when a fire is detected. They create a physical barrier between spaces inside a building. This barrier limits heat transfer and smoke movement.

The shutters are built from heat-resistant materials. They keep their shape under high temperatures and continue to function during a fire. This allows them to hold back fire for a specific period, depending on the classification.

These systems are used in warehouses, production areas and commercial buildings where large openings need protection. You can explore more solutions within the full products range.

How do fire rated rolling shutters work?

Fire rated rolling shutters are connected to the fire detection system of a building. When smoke or heat is detected, the system sends a signal to the shutter. The shutter then closes automatically using a gravity fail-safe system. This means it will also close when power is lost. Once closed, it forms a barrier that limits oxygen flow and blocks flames.

Key features of fire resistant roller shutters

Fire resistant roller shutters must perform under pressure. That is why the construction and components are designed for reliability.

Double-walled steel slats for strength and stability
Slat thickness of 22 mm for higher resistance
Automatic closing system with control box
Optical and acoustic warning signals
Designed for frequent daily use

Why choose Metacon-Next fire rated shutters?

Fire safety solutions must be predictable. They must work every time without hesitation. That is where quality and testing make the difference. Metacon-Next focuses on reliable performance and practical use. Each fire rated roller shutter is tested and certified before delivery. This ensures consistent behaviour during real fire conditions.

The systems are also designed for flexibility. Different sizes, finishes and configurations are possible. This allows the shutters to fit both standard and complex building layouts. If you want to compare other fire protection options, you can also explore fire resistant systems offered by Metacon-Next.

Applications and options

Fire rated rolling shutters are used in buildings where large openings need controlled fire separation. This often includes logistics centres, factories and commercial spaces.

The system can be adapted to different environments and requirements.

Powder coating in RAL colour for visual integration
Stainless steel components for demanding environments
Smoke detectors for stand-alone systems
Light curtains for additional safety

This flexibility allows the shutters to match both technical and visual requirements within a project.

Request a solution for your project

Fire safety is always specific to a building. The size of openings, the use of space and the required classification all influence the final solution. Metacon-Next works with a dealer network to deliver tailored systems. Each project is analysed and matched with the right configuration. If you are planning a project, you can request a quotation to receive a proposal based on your requirements.

FAQ About Fire rated roller shutters

What is a fire rated roller shutter?
A fire rated roller shutter is a steel shutter that closes automatically during a fire. It creates a barrier that slows down fire and smoke between areas in a building.

How do fire rated shutters close during a fire?
Fire rated shutters close during a fire through a connection with the fire alarm system. When triggered, the shutter drops using a gravity fail-safe system.

How long can fire resistant roller shutters resist fire?
Fire resistant roller shutters can resist fire for 60, 90 or 120 minutes, depending on the classification such as EW 60, EW 90 or EW 120.

Where are fire rated rolling shutters used?
Fire rated rolling shutters are used in warehouses, industrial buildings, parking garages and commercial spaces where fire separation is required.

Does Metacon-Next also offer burglar-resistant shutters?
Metacon-Next also offers burglar-resistant shutters and doors. You can read more about burglar-resistant solutions on the website.

Certification

tested in accordance with EN 1634-1
classified according to EN 13501-2
validated cycle test in accordance with C2 (> 10.000 cycles)
CE marked in accordance with EN 13241 and EN 16034

Application

suitable for indoor / indoor and indoor / outdoor situations
suitable for frequent use
mounting only possible on the wall / opening
permissible mounting surfaces include: aerated concrete, sand-lime brick, concrete, masonry, fire-resistant steel construction

Standard

gravity failsafe chain wheel drive 400 V incl. control box
gravity failsafe tubular motor 230 V incl. control box (till ± 8 m²)
external safety catch device
optical / acoustic signaling
door leaf constructed from double-walled, galvanized steel, slats, thickness 22 mm

Options include

application in indoor / outdoor situations up to wind class 5 (> 1.000 Pa)
roll / motor cover box, galvanized steel
galvanized steel parts powder coated in RAL color of choice
side guides, brackets, cover box in stainless steel INOX 304 or 316
set of light curtains
smoke detector for a stand-alone system
various switches

classification	fire resistance	max. opening width	max. opening height	max. opening
EW	60 minutes	9.000 mm	9.000 mm	± 56 m²
EW	90 minutes	9.000 mm	9.000 mm	± 18 m² – ± 29 m²
EW	120 minutes	9.000 mm	9.000 mm	± 14 m² – ± 25 m²

Due to continuous product development, we ask you to contact us for the current dimensions. Larger dimensions on request.

Request quote

Downloads

CE Certificates

Classification reports

User manuals

Drawings (DWG)

Product specification

Our team

Certification

tested in accordance with EN 1634-1
classified according to EN 13501-2
validated cycle test in accordance with C2 (> 10.000 cycles)
CE marked in accordance with EN 13241 and EN 16034

Application

suitable for indoor / indoor and indoor / outdoor situations
suitable for frequent use
mounting only possible on the wall / opening
permissible mounting surfaces include: aerated concrete, sand-lime brick, concrete, masonry, fire-resistant steel construction (through-and-through installation mandatory when fire resistance > 120 minutes; not possible with a steel structure surface)

Standard

gravity failsafe chain wheel drive 400 V incl. control box
external gravity failsafe tubular motor 230 V incl. control box (till ± 18 m²)
external safety catch device
optical / acoustic signaling
door leaf constructed from double-walled, galvanized steel, slats, thickness 60 mm

Options include

application in indoor / outdoor situations up to wind class 3 (700 Pa)
roll / motor cover box, galvanized steel
galvanized steel parts powder coated in RAL color of choice
set of light curtains
smoke detector for a stand-alone system
various switches

classification	fire resistance	max. opening width	max. opening height	max. opening
EW	120 minutes*	9.000 mm	8.750 mm	± 45 m²
E	240 minutes	9.000 mm	8.750 mm	± 45 m²

* additional performance EW 240 minutes is not possible to certify according EN 13501-2

Due to continuous product development, we ask you to contact us for the current dimensions. Larger dimensions on request.

Request quote

Downloads

CE certificate

CE certificaat RGS EI(1) 30 – EI(2) 60 (1812-CPR-2034)

Classification report

Classificatierapport RGS EI(1) 30 – EI(2) 60 (2021-Efectis-R001703)

User manuals

Drawings (DWG)

Drawing RGS EW 240

Product specification

Our team

Certification

tested in accordance with EN 1634-1
classified according to EN 13501-2
validated cycle test in accordance with C2 (> 10.000 cycles)
CE marked in accordance with EN 13241 and EN 16034

Application

suitable for indoor / indoor and indoor / outdoor situations
suitable for frequent use
mounting only possible on the wall / opening
permissible mounting surfaces include: aerated concrete, sand-lime brick, concrete, masonry, fire-resistant steel construction (through-and-through installation mandatory when fire resistance > 120 minutes; not possible with a steel structure surface)

Standard

construction of double, symmetrically installed, fire rated roller shutters
gravity failsafe chain wheel drive 400 V incl. control box
gravity failsafe tubular motor 230 V incl. control box (till ± 8 m²)
external safety catch devices
optical / acoustic signaling
door leafs constructed from double-walled, galvanized steel, slats, thickness 22 mm

Options include

application in indoor / outdoor situations up to wind class 5 (> 1.000 Pa)
roll / motor cover box, galvanized steel
galvanized steel parts powder coated in RAL color of choice
side guides, brackets, cover box in stainless steel INOX 304 or 316
set of light curtains
smoke detector for a stand-alone system
various switches

classification	fire resistance	max. opening width	max. opening height	max. opening
EW	60 minutes	9.000 mm	9.000 mm	± 56 m²
EW	90 minutes	9.000 mm	9.000 mm	± 56 m²
EW	120 minutes*	9.000 mm	9.000 mm	± 56 m²
EW	240 minutes*	9.000 mm	9.000 mm	± 56 m²

* additional performances EW 240 and EW 360 minutes are not possible to certify according EN 13501-2

Due to continuous product development, we ask you to contact us for the current dimensions. Larger dimensions on request.

Request quote

Downloads

CE Certificates

Classification reports

User manuals

Drawings (DWG)

Product specification

Our team

Certification

tested in accordance with EN 1634-1
classified according to EN 13501-2
validated cycle test in accordance with C2 (> 10.000 cycles)
CE marked in accordance with EN 13241 and EN 16034

Application

suitable for indoor / indoor and indoor / outdoor situations
suitable for frequent use
mounting only possible on the wall / opening
permissible mounting surfaces include: aerated concrete, sand-lime brick, concrete, masonry, fire-resistant steel construction

Standard

gravity failsafe chain wheel drive 400 V incl. control box
external gravity failsafe tubular motor 230 V incl. control box (till ± 18 m²)
external safety catch device
optical / acoustic signaling
door leaf constructed from double-walled, galvanized steel, slats, thickness 60 mm

Options

application in indoor / outdoor situations up to wind class 3 (700 Pa)
roll / motor cover box, galvanized steel
galvanized steel parts powder coated in RAL color of choice
set of light curtains
smoke detector for a stand-alone system
various switches

classification	fire resistance	max. opening width	max. opening height	max. opening
EI (1)	30 minutes	9.000 mm	8.750 mm	± 45 m²
EI (1)	45 minutes	9.000 mm	8.750 mm	± 45 m²
EI (2)	30 minutes	9.000 mm	8.750 mm	± 45 m²
EI (2)	60 minutes	9.000 mm	8.750 mm	± 45 m²

Due to continuous product development, we ask you to contact us for the current dimensions. Larger dimensions on request.

Request quote

Downloads

CE certificate

CE certificate RGS EI(1) 30 – EI(2) 60 (1812-CPR-2034)

Classification report

Classification report RGS EI(1) 30 – EI(2) 60 (2021-Efectis-R001703)

User manuals

Drawings (DWG)

Drawing RGS EI(1) 30 – EI(2) 60

Product specification

Our team

Certification

tested in accordance with EN 1634-1
classified according to EN 13501-2
classified according to EN 13501-1 on fire class B-s1, d0
validated cycle test in accordance with C3 (> 50.000 cycles)
CE marked in accordance with EN 13241 and EN 16034

Application

suitable for indoor / indoor and indoor / outdoor situations
applicable in protected escape routes, not as an escape route
mounting only possible on the wall / opening
permissible mounting surfaces include: aerated concrete, sand-lime brick, concrete, masonry, fire-resistant steel construction

Standard

gravity failsafe chain wheel drive 400 V incl. control box
external gravity failsafe tubular motor 230 V incl. control box (till ± 14 m²)
external safety catch device
optical / acoustic signaling
door leaf constructed from galvanized steel slats (front) and fire-resistant composite panels (back), total thickness 43mm, with a mixed white structure

Options include

application in indoor / outdoor situations up to wind class 5 (> 1.000 Pa)
burglar-resistant version (outside => inside) in accordance with RC 3 or RC 4
sound insulation value 32 dB or 34 dB
roll / motor cover box, galvanized steel
galvanized steel parts powder coated in RAL color of choice
composite slats in RAL color of choice based on wet painting or wrap foil
set of light curtains
smoke detector for a stand-alone system
various switches
explosion-proof (ATEX) components and marking
liquid barrier with height 300 mm

classification	fire resistance	max. opening width	max. opening height	max. opening
EI (1)	30 minutes	9.000 mm	7.500 mm	± 30 m²
EI (1)	60 minutes	9.000mm	7.500 mm	± 30 m²
EW	30 minutes	9.000 mm	7.500 mm	± 30 m²
EW	60 minutes	9.000 mm	7.500 mm	± 30 m²
